CR-818GSKD
CR-818GSKD
Functions:
Pre-milling--Adhesive welt 1--Quick melt glue + glue pot 2--Double rail head--Rough finishing--finishing--Trace trimming--Edge Shaving 1--Edge Shaving 2--strickle--Polishing 1--Polishing 2--Front and rear cleaning--Hot lamp--Automatic lifting of the compression beam
●Application：This machine is suitable for panel furniture, door panel edge sealing, customized furniture, cabinet and wardrobe, office furniture, solid wood furniture, tables, chairs, doors and windows, wood products, decoration industry, etc
●Machinable board: Density board, Ecological board, Multi-layer board, Particleboard,Flat solid wood board, Aluminum honeycomb board ,etc
Specification
Model | CR-818GSKD |
Total power | 28.87KW |
Feed speed | 15-23m/min |
Panel Width | ≧45mm |
Sheet length | ≧120mm |
Edge thickness | 0.4-3mm |
Panel Thickness | 10-60mm |
Electric lifting | 0.37KW |
Working Pressure | 0.6Mpa |
Overall Size(L x W x H) | 9750*970*1900mm |
Components Brand
Name | Brand |
Oil water separator | Easun |
Corner round cylinder | Air Tac |
Proximity switch | Nokeci |
Magnetic valve | Air Tac |
Conveying motor | CPG/GER |
PLC | Taiwan Delta |
High speed motor | Rundwords |
Glue tank sealing ring | Taiwan SOG |
Frequency converter | Taiwan Delta |
Limit switch | Korea Kacon |
Glue tank high temperature bearing | Germany SWC |
Touch screen | Lunluntongtai |
Temperature control meter | Korea Autonics |
End cutting and other Cylinder | Air Tac or WSM |
Contactor | SIMENS/Shilin, Taiwan |
