Automatic edge banding machine operation process and processing method

1. Check if the glue is in the glue box, then preheat the machine to 190-230°C (about 10-30 minutes according to the temperature difference of the climate);

2. Verify the color and specifications of the corresponding panel edge band. Only after confirmation can the next step be initiated.

3. The operator initiates machine debugging, primarily adjusting the pressure wheel pressure and trimming tools (edge knife and scraper) based on the edge band thickness. These parameters are displayed on the digital gauge. Simultaneously, the pressure wheel height is adjusted according to the plate thickness. For standard 18mm thick plates, the counter typically shows 180. However, considering minor wear on the pressure wheel, a slight downward adjustment of 0.2mm may be applied based on empirical experience.

4. After debugging, conduct parameter adjustment precision test to confirm whether the edge alignment is within 20mm after sealing, whether there is edge chipping, whether the glue line and guide circle are regular, and whether the adhesion is firm.

5. After the test is correct, the edge sealing operation begins. The component should be lifted horizontally and placed lightly on the workbench. The edge sealing surface should be tightly pressed against the stopper and then sent into the conveyor belt. For long components, the force should be pushed against the stopper until all the components enter the conveyor belt. The component and the stopper should not be separated;

6. Door panel sealing should start with height before width, while box panel sealing should begin with depth before proceeding to height or width.

7. When sealing the edges, inspect the quality and place the sealed edge panels on the tray gently after confirming compliance with quality standards, arranging them uniformly in one direction.

8. For manual trimming, use a wallpaper knife blade at a slight angle to scrape the board surface in the direction of the cut.To remove the raised part of the glue line and the edge band, the blade should be sharp and the edge band should be smooth without unevenness, edge gnawing and scratches. At the same time, the board should be cleaned with a clean cloth.

9. After completing the operation, first turn off the machine's switch, then disconnect the power supply, and finally clean the machine thoroughly.
